EMEC's motor driven pumps can be ordered with or without the digital control module.
Going Automated...is a cost saving really worth the 'manual headache?
PD pumps only have stroke length adjustment and are available with 220-240VAC or 380-415VAC motors, whereas the PDMF pumps are fully multi functional with multiple input and control methods. Read on to learn why automated is the way to go...
Features
Smart Functionality
Multi-functional
Fully Digital
Menu driven control
Product benefits
Multi-function motor pump with Inverter with large turndown ensures consistent dosing
Pump speed control via 4-20mA, pulse or ppm modes
Alarms relay inbuilt
Modbus RTU option for remote monitoring
Up to 1000 LPH dosing
Up to 100 bar injection pressure
Simple Encoder wheel menu navigation
Applications
Swimming Pool
Oil Industry
Chemical Industry
Beverage Industry
Hotel & Resorts
Food Industry
Cooling Towers
Spa
Industrial Water Treatment
Potable Water Treatment
Car Wash
Hospital
The Prius Key Features
Multifunction motor pump with inverter
Working modes: Constant, ppm, %, mlq, pause-work, weekly, mA, Volt and Batch
Level control
Programmable Alarms
Stand-by
2 possible positions of the electronic unit
PTFE diaphragm
Aluminium enclosure
Spring return mechanism
Manual degassing valve (PVDF and PP pump heads)
Stroke adjustment
Liquid ends are available in different sizes and materials
Double ball check valves
Australian Product Range and Best Sellers
PRIUS PDMF 010 060 Motor Driven dosing pump (60l/hr @ 10 bar)
PRIUS PDMF 007 160 Motor Driven dosing pump (160 l/hr @ 7 bar)
PRIUS PDMF 005 240 Motor Driven dosing pump (240l/hr @ 5 bar)
EMEC PRIUS PDMF 005 530 Motor Driven dosing pump (530l/hr @ 5 bar)
Prius Products Brochure
Installation Kits
A. Installation Kit Included without an extra price
1/2” foot filter with 13 mm (int. diam.) hose fitting
3/4” injection valve
PVDF delivery hose (13X16 PVDF or 12x18 PVC)
PVDF suction hose (13X16 PVDF or 12x18 PVC)
B. Installation Kit
1 1/2” foot filter with 18 mm (int. diam.)
hose fitting (G1 1/2” - 18 mm)
Suction hose - 18x25 PE
Delivery hose - 18x22 PVDF
C. Installation Kit
1/2” foot filter with 13 mm (int. diam.) hose fitting
3/4” injection valve
PVDF delivery hose (13X16 PVDF or 12x18 PVC)
PVDF suction hose (13X16 PVDF or 12x18 PVC)
Accessories
Pressure / Security Valve
The pressure/security valve, directly controlled by the medium, is used in technical processing plants to keep constant working pressures on the primary side.
Operating Pressure: 0,5-10 bar Opening Pressure: 0,3 bar
Pulsation Dampeners
SOIM2.5 - SOIM5 PVC pulsation dampener without membrane. FKM B o-ring. Available in 2,5 litre (SIOM2.5) and 5 litre (SOIM5).
